Kurba Max

Field Bendable 24V System

160-536 lm/ft, 3.6-5 W/ft

524.8-1758.1 lm/m, 11.8-16.4 W/m

Warm DimTunable WhiteIP68
Overview
Specifications
Metric Units

Kurba Max is a dot free direct view, highly versatile, energy efficient and flexible LED strip suitable for outdoor wet locations capable of horizontal/side bends and vertical/top bends with a 8”in bending radius. The silicone material offers excellent heat, weather, UV, and solvent resistance and has a special coating to repel dust and dirt accumulation.

  • CCT: 18K - 30K, 2200K, 22K - 57K, 2700K, 3000K, 3500K, 4000K
  • CRI: 90+
  • Type: Bendable
  • Output Per: 524.8 lm/m, 160 lm/ft, 547.8 lm/m, 167 lm/ft, 669.1 lm/m, 204 lm/ft, 682.2 lm/m, 208 lm/ft, 1098.8 lm/m, 335 lm/ft, 1298.9 lm/m, 396 lm/ft, 1433.4 lm/m, 437 lm/ft, 1758.1 lm/m 536 lm/ft
  • Mounting: Recessed, Surface
  • Bend Type: Horizontal, Vertical
  • Input Voltage: Low Voltage
  • Color: Static White, Tunable White, Warm Dim
  • Wattage Per: 11.8 W/m, 3.6 W/ft, 16.4 W/m 5 W/ft
  • Rating: IP68
  • Lens Aperture: 22.1 mm 0.87 inch
  • Size: 22.1 mm 0.87 in
  • Height: 22.098 mm 0.87 in
  • Lens: Silicone Frosted
  • Operating Temperature: -40-45 C, -40°F to 113°F, -40-55 C -40°F to 131°F
  • Sustainability: Declare, JA8/Title 24, RoHS/Reach
  • Manufacturing Details: Shipped from UK
  • Warranty: 5 Years
  • Finishes: White silicon
  • Product Number: KBX
