Field Bendable Linear

Kurba Large Sauna

Field Bendable 24V System

89-98 lm/ft, 1.8 W/ft

291.9-321.4 lm/m, 5.9 W/m

IP67
Overview
Specifications
Metric Units

Kurba Large is a dot free direct view, highly versatile, energy efficient and flexible LED strip suitable for Sauna and Spa locations capable of horizontal/side bends and vertical/top bends with a 6 in bending radius. The silicone material offers excellent heat, weather, UV, and solvent resistance and is self cleaning which repels dust and dirt accumulation.

  • CCT: 2200K, 2400K, 2700K, 3000K, 3500K, 4000K
  • CRI: 80+
  • Type: Bendable
  • Output Per: 291.9 lm/m, 89 lm/ft, 321.4 lm/m 98 lm/ft
  • Mounting: Recessed, Surface
  • Bend Type: Horizontal, Vertical
  • Input Voltage: Low Voltage
  • Color: Static White
  • Wattage Per: 5.9 W/m 1.8 W/ft
  • Rating: IP67
  • Lens Aperture: 16 mm 0.63 inch
  • Size: 16 mm 0.63 in
  • Height: 17.018 mm 0.67 in
  • Lens: Silicone Frosted
  • Operating Temperature: -40-90 C -40°F to 194°F
  • Sustainability: Declare, RoHS/Reach
  • Manufacturing Details: Made in Canada, Shipped from Canada
  • Warranty: 3 Years
  • Finishes: White silicon
  • Product Number: KBL
Learn more
Specsheets
Install Guides
Cross Reference Guide
DWG CAD
IES Files
Kurba Large V H Sauna Static White Specsheet
2.14 MB
PDF
Kurba-Install-Guide
2.14 MB
PDF
Kurba Cross Reference
581.27 KB
PDF
Kurba Large Sauna 2D Dimensioning
470.98 KB
DWG
KBL-SN-VB-48-33LO-30K-R80-SF-NA-WH.ies
3.04 KB
IES
KBL-SN-HB-48-33LO-30K-R80-SF-NA-WH.ies
3.01 KB
IES
