Kendo XL Recessed Wet

Static White & Dynamic Color

Warm DimTunable WhitePixelRGB/RGBWIP68
Overview
Specifications

Kendo XL Recessed Wet is a linear luminaire designed for architectural surface and millwork applications where clean lines and visual comfort are essential. It is available with RGB LEDs for vivid, saturated color, RGBW LEDs delivering rich whites alongside color, smart Pixel LEDs enabling dynamic, addressable color effects, Tunable White LEDs offering precise CCT control, Warm Dim LEDs that smoothly dim from warm to ultra-warm color temperatures; High Efficacy static white LEDs optimized for long runs and best-in-class efficacy, Vibrant Color static white LEDs with maximum 72 LEDs per foot for exceptional color quality and no visible dotting. The fixture delivers dot-free, even illumination with a frosted lens and supports linked runs for continuous lines of light. Additional highlights include 24VDC Class 2 and IP68 rated for wet locations, fixtures made to order up to 144”.Fixtures can be linked up to 37’ depending on output, Suitable for millwork, recessed, wet, outdoor, architectural reveals, accent light and surface mount applications, Dot free even illumination with frosted lens. Kendo XL Recessed Wet – Static White is a linear luminaire designed for architectural surface and millwork applications where clean lines and visual comfort are essential. Additional highlights include 24VDC Class 2 and IP68 rated for wet locations, fixtures made to order up to 144”. Proudly assembled in the USA. This wet-location fixture is BAA and BABA compliant.

  • Finishes: Aged Brass, Black, Bronze, Chrome, Matt Black, Polished Gold, Silver Anodized, Warm Nickel, White
  • CCT: 2200K-3000K, 2200K-3500K, 2200K-3800K, 2200K-4000K, 2700K, 3000K, 3500K, 4000K, RGB4000K
  • CRI: 98
  • Output Per: 357.5 lm/m, 109 lm/ft, 400.2 lm/m, 122 lm/ft, 403.4 lm/m, 123 lm/ft, 488.7 lm/m, 149 lm/ft, 587.1 lm/m, 179 lm/ft, 590.4 lm/m, 180 lm/ft, 616.8 lm/m, 188 lm/ft, 626.5 lm/m, 191 lm/ft, 669.1 lm/m, 204 lm/ft, 754.4 lm/m, 230 lm/ft, 757.7 lm/m, 231 lm/ft, 833.1 lm/m, 254 lm/ft, 843.2 lm/m, 257 lm/ft, 1043 lm/m, 318 lm/ft, 1075.8 lm/m, 328 lm/ft, 1102.4 lm/m, 336 lm/ft, 1118.5 lm/m, 341 lm/ft, 1332 lm/m, 406 lm/ft, 1368.1 lm/m, 417 lm/ft, 1591.2 lm/m, 485 lm/ft, 1771.7 lm/m, 540 lm/ft, 2112.9 lm/m, 644 lm/ft, 2181.8 lm/m, 665 lm/ft, 246 lm/m, 75 lm/ft, 2628 lm/m, 801 lm/ft, 272.2 lm/m, 83 lm/ft, 321.4 lm/m 98 lm/ft
  • Mounting: Recessed Trimmed
  • Type: Linear Fixture
  • Input Voltage: Low Voltage
  • Color: Pixel, RGB/RGBW, Static White, Tunable White, Warm Dim
  • Wattage Per: 3.3 W/m, 1 W/ft, 32.8 W/m, 10 W/ft, 6.7 W/m, 2 W/ft, 9.8 W/m, 3 W/ft, 13.1 W/m, 4 W/ft, 16.4 W/m, 5 W/ft, 19.7 W/m, 6 W/ft, 23 W/m, 7 W/ft, 26.3 W/m, 8 W/ft, 29.5 W/m 9 W/ft
  • Rating: IP68
  • Lens Aperture: 15.7 mm 0.62 inch
  • Size: 21.1 mm 0.83 in
  • Height: 13.97 mm 0.55 in
  • Lens: Clear Lens, Frosted Lens
  • Operating Temperature: -4°F to 104°F, -4°F to 113°F, -20-50 C, -4°F to 122°F, -4°F to 86°F, -4°F to 95°F
  • Sustainability: BAA/BABA, Declare, JA8/Title 24, RoHS/Reach
  • Manufacturing Details: Made in America
  • Warranty: 5 Years
  • Product Number: KRXLW
